classification:
Part
Application:

Acme Monaco offers custom manufactured medical guidewires for catheter manufacturers or other OEM instrument manufacturers. Our guidewires are strong, resisting doubling back or kinking during the insertion and retraction procedures yet flexible enough to negotiate the desired tortuous path of the vascular system without damaging it.

Product introduction Model specification Parameter

ACME GUIDEWIRES

Acme Monaco offers custom manufactured medical guidewires for catheter manufacturers or other OEM instrument manufacturers. Our guidewires are strong, resisting doubling back or kinking during the insertion and retraction procedures yet flexible enough to negotiate the desired tortuous path of the vascular system without damaging it.


Uncoated Spring Construction Guidewires

Stainless Steel / NiTi core

Common Uncoated Guidewire Sizes

O.D

 Length

Tip

Single Distal(SD)/

  Double Distal(DD)

 Flex Length

Safety Ribbon

 Etch Mark

Material

 Remarks

0.018”

45cm

3mm'J”

SD

3cm Flex

No

Yes

SUS304

Bulk-packed

Non-sterile

Uncoated

0.025”

50cm

3mm'J”

SD

3cm Flex

No

Yes

SUS304

0.032”

60cm

3mm'J”

DD

3cm Flex

No

Yes

SUS304/Niti core

70cm

3mm'J”

DD

3cm Flex

No

Yes

SUS304/Niti core

3mm'J"/Straight

DD

3cm Flex

No

Yes

SUS304/Niti core

0.035”

45cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

50cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

60cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

70cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

3mm'J"/Straight

DD

3cm Flex

Optional

Yes

SUS304/Niti core

0.038”

45cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

60cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

70cm

3mm'J”

DD

3cm Flex

Optional

Yes

SUS304/Niti core

3mm'J"/Straight

DD

3cm Flex

Optional

Yes

SUS304/Niti core


PTFE Coated Spring Construction Guidewires

Stainless Steel / NiTi core

Common PTFE-coated Guidewire Sizes

    O.D

Length

         Tip

Single Distal(SD)

 Flex Length

Material

     Remarks

0.018”

150cm

3mm ‘J”

Single Distal(SD)

3cm Flex

SUS304

Bulk-packed

Non-sterile

PTFE-coated



Straight

3cm Flex

SUS304

0.021”

150cm

3mm ‘J”

3cm Flex

SUS304

Straight

3cm Flex

SUS304

0.025”

150cm/260cm

3mm ‘J”

3cm Flex

SUS304/NiTi core

Straight

3cm Flex

SUS304/NiTi core

0.032”

150cm/260cm

3mm ‘J”

3cm Flex

SUS304/NiTi core

Straight

3cm Flex

SUS304/NiTi core

0.035”

150cm/260cm

3mm ‘J”

3cm Flex

SUS304/NiTi core

Straight

3cm Flex

SUS304/NiTi core

0.038”

150cm/260cm

3mm ‘J”

3cm Flex

SUS304/NiTi core

Straight

3cm Flex

SUS304/NiTi core


Hydrophilic Guidewire

“J”shaped Tip / Straight Shaped Tip / Angled Shaped Tip / BK

Common Hydrophilic Guidewire Sizes

Part Number

O.D

Tip

Length

Material

             211503TS(W)   0.021”

             Straight

           150cm

      Nitinol Corewire

        Polymer Jacketed

211503TA(W)   0.021”

Angled

150cm

Nitinol Corewire

Polymer Jacketed

251503TS(W)   0.025”

Straight

150cm

Nitinol Corewire

Polymer Jacketed

251503TA(W)   0.025”

Angled

150cm

Nitinol Corewire

Polymer Jacketed

321503TS(W)   0.032”

Straight

150cm

Nitinol Corewire

Polymer Jacketed

321503TA(W)   0.032”

Angled

150cm

Nitinol Corewire

Polymer Jacketed

351503TS(W)   0.035”

Straight

150cm

Nitinol Corewire

Polymer Jacketed

351503TA(W)   0.035”

Angled

150cm

Nitinol Corewire

Polymer Jacketed

* The above 8 kinds are common specifications, all have hydrophilic coating, the length can be customized according to your requirements.


Zebra Guidewire

Straight Shaped Tip / Angled Shaped Tip

Features

·       Nitinol core wire

·       PTFE coating

·       Super smooth tip

·       Radiopaque tip

·       Integrated design of tip and core wire, impossible for falling off

·       The design of tapering tip and suitable flexibility, easy for insertion into channel, highly increase the success rate of surgery

Specifications

Model Number

JHY-GW-035-450-C1

JHY-GW-035-150-C1

JHY-GW-032-450-C1

JHY-GW-032-150-C1

O.D.(mm/inch)

0.035"

0.035"

0.032"

0.032"

Length(cm)

450cm

150cm

450cm

150cm

Features

Super smooth soft tip; Straight shape and angled shape

Bicolor spiral
